Angular Contact Ball Bearing- Single Row / Double Row Ball Bearing

Image of Angular Contact Ball Bearing

Angular Contact Ball Bearing is ideal for applications that require high accuracy and good high-speed performance. These kinds of bearings are required to carry a combined load. Angular contact bearings come in different types and angles. The standard angles are 15 degrees, 30 degrees, 40 degrees.

Angular Contact Ball Bearings also come in matched pairs as back-to-back (DB), face-to-face (DF), and Tandem arrangements. Angular Contact Bearing is also available in Double Row consisting of two single-row angular contact ball bearings matched back to back with integrated inner and outer rings.

Specialized Angular Contact Ball Bearing comes in a four-point contact angle of 35 degrees consisting of an inner ring divided into two pieces.

Types of Angular Contact Ball Bearings

Single
Row

Image of Single Row Angular Contact Ball Bearing

BACK TO BACK
ARRANGEMENT

Image of Back to Back Angular Contact Ball Bearing

FACE TO FACE
ARRANGEMENT

Image of Face to Face Angular Contact Ball Bearing

TANDEM
ARRANGEMENT

Image of Tandem Arrangement Angular Contact Ball Bearing

Double
row

Image of Double Row Angular Contact Ball Bearing

Features And Benefits Of Angular Contact Ball Bearing

  • Bearing rings and balls possess their own contact angle that is normally 15°, 30° or 40°.
  • Bearings with a smaller contact angle are more suitable for applications involving high-speed rotation.
  • Those with a larger contact angle feature superior axial load resistance.
  • Single-row angular contact ball bearings can accommodate radial load and axial load in one direction.
  • DB and DF matched pair bearings and double-row angular contact ball bearings can accommodate radial load and axial load in both directions.
  • DT matched pair bearings are used for applications where axial load in one direction is too large for one bearing to accept.
  • Angular contact ball bearings are used for high accuracy and high-speed operation.

Application And Uses Of Angular Contact Ball Bearing

  • Angular contact ball bearings are often preloaded to enhance their rigidity and rotating performance.
  • For high-precision matched pair angular contact ball bearings of class 5 or higher, which are used in machine tools and other precision equipment, the standard preload is specified in three levels: light(L), medium(M), and heavy(H).

Angular Contact Ball Bearing Size Chart

SL
No. 		Bearing
No.		d     D     B     r
(min)		Basic
Dynamic
Load
Rating
(Cr)		            Basic
Static
Load
Rating
(Cor)		            Limiting
Speed
(min-1)
Grease
Lubrication		            Oil
Lubrication		            Mass (kg)
Single
Single DuplexSingle DuplexSingle DuplexSingle Duplex
17030150125352.113700022200015400030500023001800300024004.42
27036180280462.120700033500025200050500019001500250020009.98
37000102680.35000815023404650230001900031000260000.022
47001122880.35050880027105700220001800029000230000.024
57002153290.36150995034006850180001500024000200000.035
670031735100.364001040038007650170001300022000180000.045
770042042120.61030016700605012100150001200020000160000.079
870052547120.61130018400740014800130001000017000130000.091
9700630551311450023600101002030012000850014000110000.135
1070073562141175002850012600252009500750013000100000.17
117008406815118800305001450029000850066001100090000.21
127009457516122200360001760035000750060001000080000.265
13701050801612360038500200004000070005500920075000.285
1470115590181.13100050500262005250063005000850067000.42
1570126095181.13200051500280005600060004500760062000.45
16701365100181.13350054500310006250056004300710060000.47
17701470110201.14250069000395007850050004000660053000.66
18701575115201.14350070500415008300048003800630050000.695
19701680125221.153500865005050010100044003500580046000.925
20701785130221.154500885005350010700041003300550044000.96
21701890140241.5650001060006300012600038003200520042001.26
22701995145241.5670001090006650013300038003100520042001.36
237020100150241.5685001110007050014100036002800480038001.37
247021105160262800001300008150016300033002600440035001.73
257022110170282920001490009250018500032002500430033002.14
2670241201802829650015700010300020600029002300380030002.27
27702613020033211700019000012500025000026002200360027003.43
28702814021033212000019400013300026500024001900330026003.63
297030150225352.113700022200015400030500023001800300024004.42
307032160240382.115500025200017600035000021001700280023005.44
317034170260422.117900029100021000042000020001600260021007.87
327036180280462.120700033500025200050500019001500250020009.98
337038190290462.1218000355000277000555000180014002300190010.7
347040200310512.1226000365000277000565000170013002200180013.87
357200103090.65400880027105400220001800030000240000.034
3672011232100.676001240039607950200001600027000220000.04
3772021535110.690501470047009400170001400023000190000.048
3872031740120.61130018400630012600140001100019000150000.07
3972042047140.61450023500830016600130001000018000140000.11
407205255215115300248009700194009500800014000110000.135
